In modern steel construction, connection design is as critical as the members themselves. One of the most effective methods to create strong, efficient joints is the use of steel cleats in combination with SHS (Square Hollow Section) columns. Whether you're working on industrial sheds, commercial buildings, or modular structures, the steel cleat–SHS column pairing offers a clean, reliable, and highly adaptable solution.

This comprehensive guide focuses on how to successfully apply these components in real projects—covering installation, standards, construction sequencing, and common pitfalls.

Steel Cleats: The Essential Connector

A steel cleat is a flat or angled plate used to facilitate bolted or welded connections between beams, braces, or other structural members. Cleats can be custom-sized and drilled to suit a wide range of applications.

In structural systems that include SHS columns, cleats are often welded to the outer face of the column to provide a flat surface for bolted attachments. This is especially useful because the interior of an SHS column is difficult or impossible to access for internal bolt placement.

Key Advantages of SHS Columns

Square Hollow Section columns are becoming increasingly popular in architecture and engineering for several reasons:

  • Symmetrical geometry: Offers equal load resistance in both horizontal directions.

  • Torsional stability: Ideal for resisting twisting in wind- or earthquake-prone regions.

  • Sleek profile: Suitable for architectural exposure and modern design.

  • Ease of cleat installation: Flat external faces make cleat welding or bolting simple.

Cleat Design Considerations

The design of steel cleats used with SHS columns must adhere to structural standards while accommodating real-world construction conditions.

A. Load Transfer

Cleats must safely transfer the following forces:

  • Shear from floor beams

  • Axial tension or compression from braces

  • Moment, if the connection must resist bending (usually with reinforced cleats or end plates)

B. Bolt Layout

  • Use standard bolt spacing: generally 2–3 bolt diameters between bolts.

  • Maintain clear edge distances to prevent tearing or splitting of the cleat.

  • Use washers or stiffeners if needed to avoid crushing the SHS face.

C. Cleat Thickness

Common cleat thicknesses range from 6mm to 12mm, depending on:

  • Load magnitude

  • Bolt size

  • Span between bolts

  • Weld strength

D. Welding

  • Fillet welds are most commonly used.

  • Welds must be continuous or staggered to ensure load transfer.

  • Welding should follow AS/NZS 1554 or AWS D1.1 standards, depending on region.

Fabrication and Pre-installation

To ensure accuracy and reduce on-site errors, steel cleats should be:

  • Pre-cut and drilled in the fabrication shop.

  • Welded in jigs to guarantee precise placement on SHS columns.

  • Labeled with part IDs for easy identification during erection.

Pre-welded cleats on SHS columns are highly recommended, especially in large-scale projects, where speed and quality control are paramount.

Construction Sequence: On-Site Application

Here's how cleats and SHS columns integrate during construction:

1. Column Erection

  • SHS columns with welded cleats are lifted and placed.

  • Ensure vertical alignment and levelness before continuing.

2. Beam Installation

  • Beams are hoisted and bolted to cleats.

  • Shims or adjustable cleats may be used to correct tolerances.

3. Bracing Connection

  • Gusset-type cleats handle diagonal bracing.

  • Bolted or welded braces are attached next.

4. Inspection and Torqueing

  • Check bolt torque, cleat positioning, and welds.

  • Paint touch-ups or galvanizing repairs follow if needed.

Compliance with Building Codes

Using cleat steel with SHS columns requires adherence to national and international codes, such as:

  • AS 4100 (Australia): Design for steel structures

  • AISC 360 (USA): Specification for structural steel buildings

  • Eurocode 3 (Europe): Design of steel structures

  • IS 800 (India): Code of practice for general construction in steel

Key considerations from codes include:

  • Bolt spacing and edge distances

  • Weld throat thickness and category

  • Plate design for bearing, shear, and bending

Practical Applications

A. Industrial Sheds

  • Steel cleats allow for fast erection of wide-span purlins and girts.

  • SHS columns simplify bracing layouts.

B. Modular Buildings

  • Pre-cleated SHS columns speed up floor and wall assembly.

  • Bolted cleats allow for easy disassembly or relocation.

C. Architectural Frames

  • Exposed cleats can be styled for aesthetics.

  • Cleats are painted or powder-coated to match the structure.

Field Tips and Common Issues

While cleats are simple in concept, errors often occur during fabrication or installation. Watch for:

  • Misaligned cleats: This results in twisted beams or crooked frames.

  • Undersized welds: Can compromise safety, especially in seismic zones.

  • Improper bolt torque: May cause slippage or long-term loosening.

  • Rust under cleats: Can occur if not painted properly post-welding.

Pro Tip: Use 3D models or clash detection in BIM to avoid errors in cleat placement before steel is even cut.

Case Study: Urban Mid-Rise Office

A six-story office project in a dense urban area used SHS columns with pre-welded cleats to fast-track the steel erection phase.

  • Challenge: Tight site access and no room for cranes post-frame installation.

  • Solution: Delivered SHS columns with cleats and beams prefabricated. Used mini-cranes and manual hoists to bolt all members via cleats.

  • Result: Completed frame in 9 days instead of 14. Saved 20% on labor.

Innovations on the Horizon

Steel cleats and SHS technology continue to evolve with new tools:

  • Robotic welding: Ensures consistent cleat weld quality.

  • Augmented reality (AR): Allows field crews to view cleat positions via headset.

  • Adjustable cleats: Being developed for seismic zones to absorb energy.

Conclusion

The combination of steel cleats and SHS columns offers a winning formula for efficient, adaptable, and durable steel construction. Their ability to reduce on-site welding, support a variety of structural layouts, and comply with international standards makes them a smart choice in both basic and advanced engineering projects.

Whether you're designing a single-story warehouse or a multi-level modular building, investing in high-quality cleats and precision-welded SHS columns can dramatically improve your build speed, accuracy, and safety.
